1T0333GMAPF442478
The John Deere 333G is a large-frame compact track loader designed for demanding applications in construction, landscaping, and site development. Powered by a 100 HP Yanmar turbocharged diesel engine, it delivers robust performance and efficiency. With a rated operating capacity of 3,700 lbs and a tipping load of 10,570 lbs, the 333G offers exceptional lifting capabilities. Its vertical-lift boom design provides increased lift height and reach, making it ideal for loading trucks and handling heavy materials. The machine’s advanced hydraulic system, with optional high-flow capabilities, supports a wide range of attachments, enhancing versatility on the job site. Operator comfort is prioritized with a spacious, pressurized cab, ergonomic controls, and optional features like air conditioning and heated seats. The 333G is also compatible with John Deere’s SmartGrade™ technology, enabling precise grading and earthmoving operations.
Model: John Deere 333G
Engine: Yanmar 4TNV94FHT
Gross Power: 100 HP @ 2,500 rpm
Net Power: 96.6 HP @ 2,500 rpm
Displacement: 3.1 L (186.3 cu in)
Torque: 291 lb-ft @ 1,700 rpm
Fuel Tank Capacity: 30 gallons
Hydraulic Flow (Standard): 25 gpm
Hydraulic Flow (High-Flow Option): 41.1 gpm
System Pressure: 3,450 psi
Travel Speed (Low): 5.3 mph
Travel Speed (High): 7.8 mph
Track Width (Standard): 17.7 in
Track Width (Optional): 15.8 in
Length with Bucket: 12 ft 2 in
Width (with 17.7” tracks): 6 ft 9 in
Height to Top of ROPS: 7 ft 3 in
Height to Hinge Pin: 11 ft
Dump Height: 8 ft 10 in
Dump Reach: 28 in (Foundry Bucket), 34.6 in (Construction Bucket)
Ground Clearance: 9.4 in
Angle of Departure: 31°
Cab Features: ROPS/FOPS certified, optional air conditioning, ergonomic controls
