JCB 505-20TC Telehandler — 5,500 lb Capacity, 20 ft Lift Height, 74 HP Diesel
JCB 505-20TC Telehandler — 5,500 lb Capacity, 20 ft Lift Height, 74 HP Diesel
JCB 505-20TC Telehandler — 5,500 lb Capacity, 20 ft Lift Height, 74 HP Diesel
3198109
Location : TX Comfort 78013
Specifications
Item Description
The JCB 505-20TC is a compact telehandler designed for versatility and efficiency in confined spaces. Equipped with a 74 HP JCB by Kohler diesel engine, it delivers robust performance without the need for DPF or DEF systems. Its compact dimensions—just 6 ft 2 in tall and 6 ft wide—allow for exceptional maneuverability in tight job sites. The spacious cab features single-lever electro-servo controls, proportional auxiliaries, and optional air conditioning for enhanced operator comfort. With a maximum lift capacity of 5,500 lbs and a reach of up to 20 ft, the 505-20TC is ideal for construction, agriculture, and industrial applications.
Factory Information
Model: JCB 505-20TC
Engine: JCB by Kohler, 74 HP
Maximum Lift Capacity: 5,500 lbs
Lift Capacity at Full Height: 3,900 lbs
Lift Capacity at Full Reach: 1,750 lbs
Maximum Lift Height: 20 ft
Maximum Forward Reach: 11.5 ft
Operating Weight: 12,100 lbs
Dimensions (L x W x H): 16.4 ft x 6 ft x 6 ft 2 in
Transmission: 2-speed hydrostatic
Steering Modes: 2-wheel, 4-wheel, and crab steer
Tires: 12 x 16.5 in
Fuel Tank Capacity: 20 gallons
Hydraulic Flow (Standard): 21 GPM
Hydraulic Pressure: 3,626 psi
Cab Features: ROPS/FOPS certified, optional air conditioning, single-lever electro-servo controls
Safety Features: Hose burst check valves, reversing alarm, seat safety switch
Telematics: JCB LiveLink with GPS tracking and geofencing
